Body Diameter Inches 12.5

Body Diameter mm 317.5

Hub Type Slotted Stepped

Hub Internal Bushing No

Hub Seal Groove No

Number of Mounts 3

Mount Type Stepped Pads

Mount Threads 10mm X 15

Bolt Circle Inches 11

Pilot OD Major Inches 1.701

Pilot Type Straight

With Ring Gear No

Ring Gear Tooth Count 0

Codes Sticker JMBX, 24236469, 24239789, 24245964, 24243221

Cooling Shroud No

Billet Cover No

Pump Stall Low Stall

Turbine Internal Spline Count 36

Lock-Up Unit Yes
