🔥 Twisted Street™ 6L80E Performance Transmission

Stronger Than Stock. Daily Driver Ready. Built the Twisted Torque™ Way.

The Twisted Street™ 6L80E is our entry-level performance transmission for GM cars, trucks, and SUVs that need more than a factory-style replacement without sacrificing everyday drivability.

Every transmission is completely torn down, cleaned, inspected, and rebuilt in-house with high-energy performance clutches, new matched steels, corrected hydraulics, and a NEW pump and bellhousing assembly.

We finish every build with our Super Duty Billet Cover Torque Converter at factory stall speed — INCLUDED.

Built for stock and mildly modified applications rated up to 450 HP.

⚙️ TWISTED STREET™ 6L80E BUILD SPECIFICATIONS

✔ Complete Teardown, Cleaning & Inspection

Every transmission is disassembled, cleaned, and inspected before assembly.

✔ NEW Pump & Bellhousing Assembly

A new pump and bellhousing assembly replaces the original as part of every Twisted Street™ build.

✔ High-Energy Performance Clutches & New Steels — Application Dependent

Performance friction materials and matched steels are selected for the vehicle and intended use to deliver dependable clutch operation, heat resistance, and daily-driving performance.

✔ 1-2-3-4 Clutch Assembly

Completely inspected, rebuilt, and clearanced during assembly.

✔ 3-5-Reverse Clutch & Drum

Inspected for known cracking, weld failure, and wear. The clutch assembly is rebuilt and clearanced. Drums are reconditioned or replaced as required.

✔ 4-5-6 Clutch Assembly

Rebuilt with high-energy performance clutches and matched steels. Apply clearances are checked during assembly.

✔ Reconditioned & Recalibrated Valve Body

Hydraulic circuits are inspected and corrected for proper pressure control, clutch application, converter clutch operation, and shift performance.

✔ TransGo TCC Hydraulic Correction

Addresses known torque converter clutch regulator and clutch-select circuit concerns that can contribute to converter cycling, slipping, and inconsistent operation.

✔ Pressure Regulator & Boost Valve Corrections

Pressure-control circuits are inspected and corrected as required to maintain proper hydraulic operation and clutch apply pressure.

✔ Complete Bushing Replacement

New bushings installed throughout the transmission to restore proper support and internal clearances.

✔ New Gaskets, Seals & Sealing Rings

Complete sealing service performed during assembly.

✔ New Transmission Filter

Installed with every transmission.

✔ OE Hard Parts Inspected & Measured

Drums, shafts, hubs, planetary gearsets, and related internal hard parts are inspected for wear or damage. Parts that do not meet our build specifications are replaced.

✔ Application-Specific Assembly & Setup

Each transmission is assembled for the correct vehicle and drivetrain configuration.

💥 SUPER DUTY BILLET COVER TORQUE CONVERTER — INCLUDED

Every Twisted Street™ 6L80E includes our Super Duty Billet Cover Torque Converter at factory stall speed.

The billet cover provides a stronger converter foundation while retaining the predictable engagement and smooth driving characteristics expected from a daily-driven vehicle.

✔ Super Duty Billet Cover

✔ Factory Stall Speed

✔ Matched to Vehicle Application

✔ Included with Every Street Build

No additional converter purchase required. It's already included.

🔥 BUILT FOR

• Daily-driven GM cars, trucks, and SUVs
• Stock and mildly modified engines
• 5.3L, 6.0L, and 6.2L GM applications
• Street-driven LS combinations
• Common bolt-on performance modifications
• Light towing and hauling within vehicle-rated limits
• Customers wanting increased durability without aggressive race-transmission behavior

Performance Rating: Up to 450 HP

Vehicle weight, engine torque, modifications, tuning, tire size, and intended use are considered when determining the appropriate transmission build.

🚗 COMMON GM 6L80E APPLICATIONS

Chevrolet

• Silverado 1500
• Tahoe
• Suburban 1500
• Avalanche
• Corvette C6
• Caprice PPV
• Select Express Van applications

GMC

• Sierra 1500
• Yukon / Yukon XL
• Select Savana Van applications

Pontiac

• G8 GT / GXP — Factory automatic applications

Hummer

• H2 — Select applications

Additional factory-equipped 6L80E applications may be available.

VIN verification is required for proper fitment. Transmission selection is based on vehicle year, make, model, engine, drivetrain, and factory transmission identification.

⚡ TEHCM ELECTRONICS OPTIONS

Select your electronics package from the available product options.

✔ Blank TEHCM — INCLUDED FREE

✔ TEHCM Programmed to Your VIN — +$399

VIN required when selecting the programmed option. Applicable installation setup and relearn procedures may still be required.

🔒 2-YEAR UNLIMITED MILEAGE WARRANTY

Every Twisted Street™ 6L80E includes our 2-Year Unlimited Mileage Manufacturer Defect Warranty.

Warranty coverage is subject to Twisted Torque's written warranty terms, installation requirements, and exclusions.

⭐ WHY CHOOSE TWISTED STREET™?

✔ NEW Pump & Bellhousing Assembly

✔ High-Energy Performance Clutches & New Matched Steels

✔ Rebuilt & Clearanced Clutch Assemblies

✔ Reconditioned & Recalibrated Valve Body

✔ TransGo TCC Hydraulic Corrections

✔ Pressure Regulator & Boost Valve Corrections

✔ Complete Bushing & Sealing Service

✔ Super Duty Billet Cover Torque Converter INCLUDED

✔ Factory Stall Speed

✔ Application-Specific Build

✔ 2-Year Unlimited Mileage Warranty

✔ Built In-House by Transmission People with 30+ Years Behind the Bench

🔥 NEED MORE THAN STREET?

The Twisted Street™ 6L80E is designed for dependable daily driving and mild performance applications up to 450 HP.

Running higher horsepower, boost, nitrous, aggressive tuning, larger tires, or serious track use?

Check out our Twisted Pro™ and Punisher™ 6L80E Performance Transmissions for more demanding applications.

Tell us the vehicle. Tell us the motor. Tell us the modifications. Tell us how you're actually going to drive it.

We'll help match the right transmission to your build.

📞 833-858-9612

Twisted Torque™ — Built for the Application. Not the Catalog.
