TWISTED PRO™ 6R140 GAS PERFORMANCE TRANSMISSION

Ford 6.2L V8 & Select 6.8L V10 Gas Applications

Rated Up To 550 HP / 650 LB-FT

Stock-Stall Torque Converter Included

The Twisted Pro™ 6R140 builds on our Street™ package for modified gas trucks, heavier towing, tuned applications, oversized tires and severe-duty use.

The Pro steps up to GPZ performance clutches, Kolene steels and a standard Sonnax hydraulic upgrade package for increased clutch holding capacity, heat resistance and hydraulic control.

━━━━━━━━━━━━━━━━━━━━━━

TWISTED PRO™ BUILD SPECS

CLUTCHES

✔ UPGRADED Twisted Torque™ Performance Clutch & Steel Package

✔ Raybestos GPZ Performance Frictions

✔ Kolene® Steel Clutch Plates

✔ Year/application-correct clutch configuration

✔ Clutch drums inspected

✔ Apply components inspected

✔ Clutch clearances set and verified

VALVE BODY & HYDRAULICS

✔ Year/application-correct valve body and separator plate

✔ Valve body completely disassembled and cleaned

✔ Valve bores inspected for wear

✔ Critical hydraulic circuits checked for leakage

✔ UPGRADED Twisted Torque™ Performance Hydraulic Package

✔ Sonnax 6R140 hydraulic upgrades installed standard

✔ Main pressure-regulator circuit inspected

✔ Solenoid-feed pressure circuit inspected

✔ TCC / converter-charge circuits inspected

✔ Clutch-control circuits inspected

✔ Additional Sonnax oversized valve/bore corrections installed where required

✔ Worn valve bodies repaired or replaced

COOLING & LUBRICATION

✔ Thermal cooler-bypass system inspected

✔ Cooler circuit inspected

✔ Converter-charge circuit inspected

✔ Lubrication circuit inspected

✔ Sonnax cooler-bypass correction installed where appropriate for application and operating conditions

PUMP

✔ Pump completely disassembled

✔ Pump body and components inspected

✔ Pump bushings and bearing surfaces inspected

✔ Pressure-regulation circuit inspected

✔ Converter-charge and lubrication circuits inspected

✔ Pump clearances checked

✔ Pump repaired or replaced as required

HARD PARTS

✔ Forward / Overdrive drum inspected

✔ Input shaft and splines inspected

✔ Clutch drums and hubs inspected

✔ Planetary assemblies inspected

✔ One-way clutch components inspected

✔ Output shaft/components inspected

✔ Bearing and bushing surfaces inspected

Cracked, worn or questionable hard parts are replaced.

BUSHINGS & SEALS

✔ New bushing package

✔ New sealing rings

✔ New seals and gaskets

✔ New O-rings

✔ Bonded/molded pistons replaced as required

INTERNAL ELECTRONICS

✔ Solenoids inspected and tested

✔ Solenoid configuration verified during assembly

✔ Internal harness and sensors inspected and tested

✔ Internal mode/range components inspected and tested

✔ Failed or out-of-spec electronic components replaced

✔ Solenoid Body Strategy and ID documented with every completed transmission

━━━━━━━━━━━━━━━━━━━━━━

STOCK-STALL TORQUE CONVERTER INCLUDED

Every Pro™ 6R140 includes a professionally remanufactured gas 6R140 stock-stall torque converter matched to the application.

✔ Stock stall speed

✔ Factory-style lockup

✔ Application-matched configuration

✔ Converter clutch and internal components inspected/rebuilt

✔ Converter balanced after assembly

Heavy-Duty Billet Quad-Clutch Torque Converter upgrade available.

━━━━━━━━━━━━━━━━━━━━━━

RATED FOR

Up To 550 HP / 650 LB-FT

Recommended for:

✔ Modified 6.2L gas trucks

✔ Tuned applications

✔ Heavy towing and hauling

✔ Oversized tires

✔ Work and service trucks

✔ Fleet and commercial use

✔ Mild forced-induction applications within rated power

✔ Street performance

Higher-output or extreme-duty combinations should move to the Twisted Punisher™ 6R140.

━━━━━━━━━━━━━━━━━━━━━━

FITMENT

6.2L Gas V8

Select Ford Super Duty applications originally equipped with the 6R140.

6.8L Gas V10

Select Super Duty, commercial and medium-duty applications originally equipped with the 6R140.

Available configurations include:

2WD Slip Yoke • 2WD Flange Yoke • 4WD • PTO • Non-PTO

VIN REQUIRED

Ford made multiple changes to the 6R140 throughout production. VIN and application are verified for the correct valve body, separator plate, output configuration, converter and calibration.

We build to the application, not just the model year.

━━━━━━━━━━━━━━━━━━━━━━

INSTALLATION & PROGRAMMING

The Solenoid Body Strategy and ID supplied with the transmission must be verified during installation.

Installer requirements:

✔ Verify supplied Solenoid Body Strategy/ID

✔ Program the supplied strategy if required

✔ Reset transmission adaptive values / Keep Alive Memory as required

✔ Complete the Ford adaptive relearn procedure

✔ Verify fluid level at the proper operating temperature

✔ Flush and flow-test cooler and cooler lines before operation

Modified vehicles require proper engine/transmission calibration for power level, tire size, axle ratio and intended use.

━━━━━━━━━━━━━━━━━━━━━━

TWISTED PRO™ 6R140

550 HP / 650 LB-FT

UPGRADED FROM STREET™

Raybestos GPZ Performance Frictions

Kolene® Steels

Twisted Torque™ Performance Hydraulic Package

Sonnax Hydraulic Upgrades Installed Standard

Additional Valve-Bore Corrections As Required

Stock-Stall Converter Included

BUILT STRONG. BUILT TWISTED.
