💥 Twisted Street™ Ford C4 Transmission

Rated Up to 350 HP / 350 LB-FT

2WD Street Performance • Daily Drivers • Restorations • Classic Ford Builds

The Twisted Street™ C4 is our street-performance build for stock and mildly modified small-block Ford applications.

Built for classic Mustangs, Cougars, Falcons, Fairlanes, Mavericks, street rods and restorations that still need normal automatic operation with a clean, positive shift.

🔧 BUILD SPECS

• New Clutches & Steels
• Upgraded Intermediate Band
• Low/Reverse Band Serviced as Required
• Complete New Gasket, Seal & Sealing Ring Kit
• New Pump Bushing
• New Extension Housing Bushing
• Remaining Bushings & Thrusts Serviced as Required
• One-Way Clutch Serviced as Required
• Planetary & Geartrain Checked and Serviced as Required
• Intermediate Servo Rebuilt with New Seals
• New Filter

⚙️ PUMP & VALVE BODY

• Front Pump Completely Disassembled & Rebuilt
• Pump Gears, Pocket & Stator Support Checked
• Pump Clearances Checked
• Pressure Regulator Circuit Checked
• Valve Body Completely Disassembled & Rebuilt
• TransGo Calibration Matched to C4 Year & Valve Body
• Line Pressure & Shift Timing Calibrated for Street Use
• Governor & Modulator Set Up for Application
• Transmission Endplay Checked & Set
• Bands Adjusted to Proper Specification

🔥 STREET CALIBRATION

This is a forward-pattern automatic C4, not a full-manual race transmission.

Put it in Drive and drive it.

The Street is calibrated for a clean, positive 1–2 and 2–3 shift without the harsh operation of a race valve body.

⚠️ TORQUE CONVERTER NOT INCLUDED

Please select a torque converter from the available options if one is needed.

If you purchase a converter with your transmission, we will supply the correct converter to match the C4 being built.

If you are reusing your existing converter, you MUST verify whether it is 24-spline or 26-spline before ordering.

⚠️ PLEASE CONFIRM 157T OR 164T

You MUST verify whether your current application uses a:

• 157-Tooth Application
• 164-Tooth Application

Flexplate is NOT included.

⚠️ 1964½ & EARLY FORD APPLICATIONS

If you have a 1964½ or early Ford application, please confirm your 5-bolt or 6-bolt bellhousing pattern before ordering.

Do not go by vehicle year alone. Many of these vehicles have had the engine, transmission or bellhousing changed over the years.

🚗 APPLICATION

Up to 350 HP / 350 LB-FT

Built for stock and mildly modified:

• 260 / 289 / 302 Ford Small Blocks
• Mild 351W Applications
• Classic Ford Street Cars
• Restorations
• Street Rods
• Weekend Cruisers

Standard configuration is 2WD. 4x4 applications are available separately.

Running more than 350 HP / 350 LB-FT? Step up to the Twisted Pro™ C4.
