💥 Twisted Pro™ Ford C4 2WD Transmission

Rated Up to 450 HP

2WD Performance Street • Weekend Strip • Classic Ford Builds

The Twisted Pro™ C4 is for drivers who need more holding power and a firmer shift than our Twisted Street™, while keeping normal automatic operation.

Put it in Drive and drive it. This is a performance street build for modified small-block Ford applications, classic cars and weekend builds.

🔧 BUILD SPECS

• 5-Clutch Forward Pack
• 5-Clutch Direct/High Pack
• Performance Frictions in the Forward and Direct/High Packs
• New Matched Steels in Both Packs
• New Performance Intermediate Band
• Low/Reverse Band Serviced as Required
• Complete New Gasket, Seal & Sealing Ring Kit
• Complete Replacement of All Applicable Serviceable Bushings
• Thrust Components Checked and Serviced as Required
• New Applicable One-Way Clutch
• Planetary & Geartrain Checked and Serviced as Required
• Intermediate Servo Rebuilt with New Seals
• New Filter

⚙️ PUMP & VALVE BODY

• Front Pump Completely Disassembled & Rebuilt
• Pump Gears, Pocket & Stator Support Checked
• Pump Clearances Checked
• Pressure Regulator Circuit Checked
• Valve Body Completely Disassembled & Rebuilt
• Year- and Valve-Body-Matched TransGo Performance Calibration
• Line Pressure & Shift Timing Calibrated for Firmer Pro Street Shifts
• Governor & Modulator Set Up for Application
• Transmission Endplay Checked & Set
• Forward and Direct Clutch Clearances Checked & Set
• Bands Adjusted to Proper Specification

🔥 PRO STREET CALIBRATION

This is a forward-pattern automatic C4, not a full-manual or reverse-pattern race transmission.

Put it in Drive and let it shift automatically. The Pro is calibrated for a firmer, quicker 1–2 and 2–3 shift than our Street build without turning your classic Ford into a harsh race-only car.

The performance intermediate band and valve-body calibration are selected and set up together for the C4 being built.

⚠️ TORQUE CONVERTER NOT INCLUDED

Please select a torque converter from the available options if one is needed.

If you purchase a converter with your transmission, we will supply the correct converter to match the C4 being built.

If you are reusing your existing converter, you MUST verify whether it is 24-spline or 26-spline before ordering.

⚠️ PLEASE CONFIRM 157T OR 164T

You MUST verify whether your current application uses a:

• 157-Tooth Application
• 164-Tooth Application

Flexplate is NOT included.

⚠️ 1964½ & EARLY FORD APPLICATIONS

If you have a 1964½ or early Ford application, please confirm your 5-bolt or 6-bolt bellhousing pattern before ordering.

Do not go by vehicle year alone. Many of these vehicles have had the engine, transmission or bellhousing changed over the years.

🚗 APPLICATION

Rated up to 450 HP

Built for properly matched:

• Modified 289 / 302 Ford Small Blocks
• Mild to Moderate 351W Applications
• Classic Ford Street Cars
• Street Rods and Restorations
• Weekend Cruisers
• Occasional Strip Use

Standard configuration is 2WD. C4 Pro 4x4 applications have a separate pan-fill and 4x4 fitment specification.

Tell us your engine combination, estimated horsepower and torque, vehicle weight, tire size and intended use so we can confirm this is the right C4 for your build.
